Main Specifications
Resolution
1080p (1920 x 1080)
Brightness (ANSI lumens)
2800
Contrast Ratio (FOFO)
10000:1
Speaker
10Wx2
All Specifications
Display
Projection System
DLP
Resolution
1080p (1920 x 1080)
Resolution Support
VGA(640 x 480) to WUXGA_RB (1920 x 1200) *RB = Reduced Blanking
Brightness (ANSI lumens)
2800
Contrast Ratio (FOFO)
10000:1
Display Color
30 Bits (1,07 billion colors)
Native Aspect Ratio
16:9
Light Source
Lamp
Light Source Wattage
240W
Light Source Life
Normal 3000 hours
Economic 4000 hours
SmartEco 6000 hours
Optical
Throw Ratio
0.23
Zoom Ratio
Fixed
Lens
F/# = 2.4, f = 3.35 mm
Keystone Adjustment
1D, Vertical ± 30 degrees
Projection Offset
138%
Clear Image Size (Diagonal)
86"~130''
Image Size
30''~300''
Horizontal Frequency
15 ~102KHz
Vertical Scan Rate
23~120Hz
Picture Mode
3D;Bright;Cinema;Game;User 1;User 2;Vivid
Color Wheel Segment
6 segment (RGBYCW)
Color Wheel Speed
2X
Audio
Speaker
10Wx2
Interface
PC (D-Sub)
2
Monitor Out (D-Sub)
1
Composite Video in (RCA)
1
Component Video In
2
HDMI
2
HDMI-1 (1.4a/HDCP1.4)
HDMI-2 (1.4a/MHL/HDCP1.4)
USB Type mini B
1
USB Type Mini B-1(service)
Audio in (3.5mm Mini Jack)
2
Audio L/R in (RCA)
1
Audio out (3.5mm Mini Jack)
1
RS232 (DB-9pin)
1
IR Receiver
1(Front)
Security Bar
1
Compatibility
HDTV Compatibility
480i, 480p, 576i, 567p, 720p, 1080i, 1080p
Video Compatibility
NTSC, PAL, SECAM
3D Compatibility
Frame Sequential: Up to 720p
Frame Packing: Up to1080p
Side by Side: Up to 1080i/p
Top Bottom: Up to 1080p
Environment
Power Supply
AC100 to 240 V, 50 to 60 Hz
Typical Power Consumption
400W
Standby Power Consumption
< 0.5W
Acoustic Noise (Typ./Eco.)
35/29 dB
Operating Temperature
0~40?
Dimension and Weight
Dimensions (W x H x D)(mm)
385 x152 x429
Net Weight (Kg/ lbs)
6.2
Accessories (Standard)
Carton
Yes
Remote Control w/ Battery
Yes (RCS011)
Power Cord (by region)
Yes (2.9M)
User Manual CD
Yes
Quick Start Guide
Yes
Warranty Card (by region)
Yes
Battery
Yes
Accessories (Optional)
Universal Ceiling Mount
Yes
3D Glasses
Yes
OSD
OSD Language
Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese(28 Languages)
